Overview
Anatomy는 Ryan(@wheresryan22)이 Claude Code용으로 만든 스킬입니다. 예를 들어 ‘자물쇠가 열리는 원리’를 부탁하면, 상자와 화살표로 된 도표 대신 그 원리를 그대로 몸에 담은 실제 같은 기계를 만들어, 비스듬히 위에서 내려다본 입체 그림(아이소메트릭)으로 그립니다. 한 그림은 40개 이상의 작은 부품으로 이루어지고, 끌거나 누르면 실제로 움직이며 화면의 숫자도 같은 원리로 바뀝니다. 불·물·빛 효과(WebGL)나 실제로 도는 3D 부품을 더할 수 있고, A4 포스터·도면·안내서로 인쇄할 수도 있습니다. 결과물은 웹페이지에 바로 넣는 SVG·HTML 또는 React 부품입니다. 시계 무브먼트, 로켓 엔진부터 해시맵·TCP 연결 같은 컴퓨터 개념까지, 공식 예시와 다른 사람들의 작품을 원작 사이트에서 볼 수 있습니다.
Anatomy is a Claude Code skill by Ryan (@wheresryan22). Ask, for example, how a lock opens, and instead of a diagram of boxes and arrows it invents a real-looking machine that embodies the idea and draws it as an isometric figure. Each figure is built from 40 or more small parts; drag or press it and it really moves, and the readouts come from the same model. You can add fire, water and light effects (WebGL) or parts that truly turn in 3D, and print it as an A4 poster, drawing or handout. The result is SVG and HTML, or React components, ready to drop into a web page. The original site shows official examples, from a watch movement and a rocket engine to hash maps and TCP handshakes, plus a community gallery.
Inputs
- Claude Code(또는 Codex 등)에서 열어 둔 프로젝트
- Node.js 22.20 이상(설치 명령에 필요)과 Chrome(그림 확인에 사용)
- 설명할 개념 한 줄과, 꼭 맞아야 하는 실제 수치
- 그림이 들어갈 곳 (예: Next.js 문서, 어두운 테마)
- A project open in Claude Code (or Codex and others)
- Node.js 22.20 or later (for the install command) and Chrome (for checking the figure)
- The idea in one line, plus any real numbers that must be right
- Where the figure will go (for example, Next.js docs, dark theme)
Use Cases
- 강의·문서에서 어려운 개념을 움직이는 그림으로 설명하기 (예: 해시맵, TCP 연결, 경사하강법)
- 제품이나 기계의 구조를 분해해 보여 주기 (예: 시계 무브먼트, 로켓 엔진)
- 랜딩 페이지나 블로그에 눌러 볼 수 있는 대표 그림 넣기
- 불·물·빛이 움직이는 장면을 WebGL 효과로 만들기
- A4 포스터, 기술 도면, 2~4쪽 안내서로 인쇄하기
- Explain a hard idea in a course or document with a moving figure (hash maps, TCP handshakes, gradient descent)
- Take a product or machine apart to show how it is built (a watch movement, a rocket engine)
- Add a figure people can press to a landing page or blog
- Build fire, water and light scenes with WebGL effects
- Print as an A4 poster, a technical drawing or a 2–4 page handout
Not For
- 빠르게 만드는 간단한 도표 — 그림 하나에 30분~몇 시간이 걸립니다
- 사진 같은 이미지나 다른 사람의 그림을 그대로 따라 그리기
- 코드 프로젝트 없이 Claude 앱 대화창에서만 쓰기
- 한 번에 완성 — 첫 결과는 초안으로 보고, 어색한 점을 말해 다시 고칩니다
- Quick, simple diagrams — one good figure takes 30 minutes to several hours
- Photo-like images, or copying someone else's drawing
- Chat-only use in the Claude app without a code project
- Getting it right in one go — treat the first figure as a draft and say what feels off
Outputs
- Interactive SVG
- React Component
- WebGL Effects
- A4 Print Sheet
Try It
- /anatomy 핀 텀블러 자물쇠가 열리는 원리를 설명해 줘, interactive
- /anatomy 가스버너가 공기와 연료를 섞는 원리를 설명해 줘, interactive, WebGL
- /anatomy React가 목록을 다시 그리는 방식을 설명해 줘, interactive. 우리 Next.js 문서에 넣을 React 부품으로, 어두운 테마로.
- /anatomy explain how a pin tumbler lock opens, interactive
- /anatomy explain how a gas burner mixes air and fuel, interactive, WebGL
- /anatomy explain how React reconciles a list, interactive, as React components for our Next.js docs, dark theme
설치 안내Installation
- 컴퓨터에 Node.js 22.20 이상과 Chrome이 있는지 확인합니다.
- 터미널에서 실행합니다: npx skills add wheresryan22/anatomy -g (-g는 모든 프로젝트에서 쓰도록 설치합니다)
- 어떤 도구에 설치할지 물으면 Claude Code(또는 Codex 등)를 고릅니다. 묻지 않게 하려면 끝에 -a claude-code를 붙입니다.
- Claude Code에서 /anatomy 뒤에 설명할 개념을 적습니다. Codex에서는 $anatomy를 씁니다.
- 움직이게 하려면 interactive, 불·물·빛 효과는 WebGL, 실제 회전은 3D(시험 단계)를 같은 줄에 덧붙입니다.
- Check that Node.js 22.20 or later and Chrome are installed.
- In a terminal, run: npx skills add wheresryan22/anatomy -g (-g installs it for every project)
- When asked which tool to set up, choose Claude Code (or Codex and others). Add -a claude-code to skip the question.
- In Claude Code, type /anatomy followed by the idea. In Codex, use $anatomy.
- Add interactive to make it move, WebGL for fire, water and light, or 3D (beta) for parts that really turn, on the same line.
출처와 구성Source & Contents
- 출처: wheresryan22/anatomy · MIT ↗
- 실행되는 코드: kit/ (15 · iso-kit), scripts/ (59 · Chrome checks), examples/ (32)
- 파일: SKILL.md · references 10 · examples 9 · kit · scripts (173 files, about 10 MB)
- 외부 서비스: 없음
- Source: wheresryan22/anatomy · MIT ↗
- Code that runs: kit/ (15 · iso-kit), scripts/ (59 · Chrome checks), examples/ (32)
- Files: SKILL.md · references 10 · examples 9 · kit · scripts (173 files, about 10 MB)
- External services: None
